The rotary counter pressure filler-seamer system is suitable for beer & carbonated drink can filling and seaming. The technology of filling valve and control system adopt original technology of Germany, while seaming technology is that of Switzerland. The machine adopts advanced mechanical, electrical and pneumatic control technology. Features: working stable, accurate filling level, attractive appearance, low O2 pickup, low liquid lost and convenient maintenance.

No.	Item	Parameter
1	Capacity	300CPM (based on 330ml can)
2	Filling valve	30
3	Seaming head	4
4	Filling temperature	2-4℃
5	Filling method	Pressure equalization
6	Exhaust oxygen device	CO2 automatic purge of displacement
7	Distance between filling valves	163.36mm
8	Beer bowl up, down regulation system	electric
9	Filling level accuracy	±2mm
10	Working type	Filler driving force from seamer
11	Inlet and outlet of can direction	360 degrees
12	Total power	7.2KW
13	Motor Brand	SEW
14	PLC	Siemens
15	Inverter	DANFOSS
16	Bearing brand	SKF or NSK
17	Overall Size (L*W*H)	4823*2607*2170mm
